Square Glass Clamp for Flat Surface, 4-Pack

Square Glass Clamp for Flat Surface, 4-Pack

Name: Square Glass Clamp for Flat Surface, 4-Pack
Brand: Inline Design
SKU: GCL.SQU.FLT.PK4.BLK
Price: 79.96 USD
Availability: OutOfStock

GCL.SQU.FLT.PK4.BLK

$79.96 $51.96 Save 35%

Shipping calculated at checkout.

Finish

Satin Stainless Steel (SS 316)

Black Matte (SS 304)

Quantity

[{"id":41144682578083,"title":"Satin Stainless Steel (SS 316)","option1":"Satin Stainless Steel (SS 316)","option2":null,"option3":null,"sku":"GCL.SQU.FLT.PK4","requires_shipping":true,"taxable":true,"featured_image":{"id":20925481615523,"product_id":5765808980131,"position":2,"created_at":"2021-01-20T07:37:03-08:00","updated_at":"2025-04-24T06:46:06-07:00","alt":null,"width":3000,"height":2899,"src":"\/\/inlinedesign.com\/cdn\/shop\/products\/glass-clamp-square-pack-of-four.jpg?v=1745502366","variant_ids":[41144682578083]},"available":false,"name":"Square Glass Clamp for Flat Surface, 4-Pack - Satin Stainless Steel (SS 316)","public_title":"Satin Stainless Steel (SS 316)","options":["Satin Stainless Steel (SS 316)"],"price":7996,"weight":1860,"compare_at_price":9996,"inventory_management":"shopify","barcode":"615867826757","featured_media":{"alt":null,"id":13100131123363,"position":2,"preview_image":{"aspect_ratio":1.035,"height":2899,"width":3000,"src":"\/\/inlinedesign.com\/cdn\/shop\/products\/glass-clamp-square-pack-of-four.jpg?v=1745502366"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":43665195827363,"title":"Black Matte (SS 304)","option1":"Black Matte (SS 304)","option2":null,"option3":null,"sku":"GCL.SQU.FLT.PK4.BLK","requires_shipping":true,"taxable":true,"featured_image":{"id":38298083328163,"product_id":5765808980131,"position":3,"created_at":"2024-02-02T12:24:33-08:00","updated_at":"2025-04-24T06:30:05-07:00","alt":null,"width":1706,"height":1706,"src":"\/\/inlinedesign.com\/cdn\/shop\/files\/009.53-4.jpg?v=1745501405","variant_ids":[43665195827363]},"available":true,"name":"Square Glass Clamp for Flat Surface, 4-Pack - Black Matte (SS 304)","public_title":"Black Matte (SS 304)","options":["Black Matte (SS 304)"],"price":5196,"weight":1860,"compare_at_price":7996,"inventory_management":"shopify","barcode":"818228027897","featured_media":{"alt":null,"id":30766186397859,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1706,"width":1706,"src":"\/\/inlinedesign.com\/cdn\/shop\/files\/009.53-4.jpg?v=1745501405"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Stainless Steel Care Advisory Products or variants containing exposed stainless steel offer excellent corrosion resistance but are not rust-proof or stain-proof. Periodic cleaning and maintenance are required, especially in coastal, poolside, and high-chloride environments. See our Stainless Steel Disclaimer and Care & Maintenance Guide.

The Stainless Steel Square Glass Clamp for Flat Tubing (Pack of 4) is an integral component of the Chicago Square glass railing system, guaranteeing a railing system that is sleek in design, easy to install, and, most importantly, safe and durable — suited to residential and commercial settings alike. It is now compatible with 9/16" laminated glass panels.

Each clamp includes an optional safety pin. The glass panels are primarily held securely in place by compression; the pin serves as a fail-safe, catching the panel if the compression of all clamps ever fails — recommended especially for fascia-mounted posts, where the falling hazard is greater than on surface-mounted installations. If you use the safety pins, design panels with two notches per panel, at either the two top clamps or the two bottom clamps; refer to the notch placement drawing below for accurate dimensions, since glass thickness varies by manufacturer.

Quick Product Highlights

Product	Square Glass Clamp for Flat Tubing, Pack of 4
Category	Glass Clamp
System	Chicago Square Glass Railing System
Finish Options	316 Satin Stainless Steel and Black Matte Powder Coat over 304 Stainless Steel
Pack Quantity	4 clamps

Details

Finish	ASTM A480 No. 4 linearly textured satin finish
Included per Clamp	(2) gaskets for 3/8" glass, (2) gaskets for 1/2" glass, (2) gaskets for 9/16" glass, (1) safety pin
Glass Compatibility	3/8" (9.52mm), 1/2" (12.7mm), or 9/16" glass

Links & Downloadable Materials

Glass Clamp Square Flat Surface Drawing

Notch Placement Drawing

Explore our range of modern railing systems including cable railing systems, glass railing systems, and stainless steel railings — perfect for indoor and outdoor applications.

Glass Clamp - Square

Part Number:GCSF.217.167

The Premium-grade stainless steel Square Glass Clamp for Flat Tubing is a part of our Chicago Square style glass railing system. This Premium-grade stainless steel square glass clamp to ensure a railing system that is sleek in design, easy to install and still safe and sturdy upon completion.

This clamp comes with a safety pin for the glass panels. Using the safety pin is highly recommended. Glass thicknesses vary depending on the glass manufacturer. Inline Design is not liable for any slippage for failing to use the glass safety pin. Please refer the drawing for notch's dimensions to use the glass safety pin.

It is the prefect candidate to be used as a glass barrier around pools, rooftop patios, balconies, garden guardrails among other scenarios.

Details:

Suitable for Glass Thickness of 3/8” - 1/2”
For Commercial or Residential
AISI 316Premium-grade stainless steel
FinishASTM A480No 4 linearly textured satin finish

Links & Downloadable materials:
